Walking Floor Trailers
Bulk loose material and palletised goods
| Overall Height | 4.20m |
| Aperture Height (to apex) | 2.6m |
| Trailer Width | 2.55m |
| Trailer Length | 13.60m |
| Volume up to | 91m³ |
High-Volume Walking Floor Trailers
Bulk loose material and palletised goods
| Overall Height | 4.67m |
| Aperture Height (to apex) | 3m |
| Trailer Width | 2.55m |
| Trailer Length | 13.60m |
| Volume up to | 106m³ |
Long Extra High-Volume Walking Floor Trailers
Bulk loose material and palletised goods
| Overall Height | 4.67m |
| Aperture Height (to apex) | 3m |
| Trailer Width | 2.55m |
| Trailer Length | 14.53m |
| Volume up to | 111m³ |
Chipliner Trailers (with or without forklift)
Bulk loose material and palletised goods
| Overall Height | 4.46-4.66m |
| Aperture Height (to pelmet) | 2.69-2.99m |
| Trailer Width | 2.55m |
| Trailer Length (without forklift) | 13.60m |
| Trailer Length (with forklift) | 15.00m (forklift is 1.4m) |
| Volume up to | 110m³ |
Tipper Units
Bulk loose material and animal feed transport
| Overall Height | 3.80m |
| Fully Tipped Height | 10.87m |
| Trailer Width | 2.55m |
| Trailer Length | 11.50m |
| Volume | 57m³ |
Bulk Blower Units
Bulk loose sawdust, flake and animal feed transport
| Overall Height | 3.93m |
| Trailer Width | 2.55m |
| Trailer Length | 11.00m |
| Volume | 53m³ |
Timber Crane and Drag Trailer
Roundwood forestry transport
| Overall Height | 4.20-4.50m |
| Crane Max. Radius | 7.90m |
| Crane Max. Loading at | 1220kg |
| Load Width | 2.35m |
| Prime Mover Load Length | 6.90m |
| Trailer Load Length | 6.20m |
| Width | 2.55m |
Timber Crane Trailers
Roundwood forestry transport
| Overall Height | 4.20-4.50m |
| Crane Max. Radius | 9.60m |
| Crane Max. Loading at | 9.60m 1100kg |
| Load Width | 2.35m |
| Trailer Width | 2.55m |
| Trailer Length | 13.50m |
Flat Bed/Skeletal Trailers
Roundwood forestry and milling co-product transport
| Overall Height (Skeletal Trailer) | 4.20-4.50m |
| Trailer Width | 2.55m |
| Trailer Length | 13.50m |
Eight Wheeled Unit
Bulk loose sawdust, flake and animal feed transport
| Overall Height | 3.90m |
| Overall Length | 9.50m |
| Overall Width | 2.55m |
| Body Length | 7.14m |
CAT 2 Low Loader
Transport of heavy plant and machinery
| Deck Height | 0.90m |
| Trailer Width | 2.54m |
| Trailer Length | 13.60m |
| Gross Train Weight | 80 tonnes |
Urea-Based Resin Transport Trailer
For carrying liquid resin, used in board manufacture
Following discharge, the collapsible neoprene resin bag is quickly rolled up and stowed at the back of the trailer, leaving ample room for general frieght; usually board collected ready for the return run from the mill
| Overall Height | 4.20m |
| Trailer Width | 2.55m |
| Trailer Length | 13.60m |
| Resin Tank Volume | 20,000 litres |
